SKU: RIBL1145

Harken Element Single Swivel Block With Fiddle, Swivel, Becket

£99.99
Tax included Shipping calculated at checkout.
Size

Harken Element Single Swivel Block With Fiddle, Swivel, Becket

Element blocks introduce sideplates that combine forged aluminum and compound curves for strength. They are simultaneously contemporary and very robust. Element’s design pairs the minimum amount of metal required to protect the sheave with a proven journal bearing.

So size for size, Element is priced significantly lower, than our previously least expensive blocks. Sideplates are hardcoat-anodized to resist corrosion. A tough composite bearing sheave resists corrosion for a long service life.



Specifications

Harken Reference 6263
Sheave Ø (mm) 60 mm
Sheave Ø (in) 2 3/8 in
Length (mm) 181 mm
Length (in) 7 1/8 in
Weight (g) 250 g
Weight (oz) 8.75 oz
Shackle pin Ø (mm) 6 mm
Shackle pin Ø (in) 1/4 in
Maximum line Ø (mm) 10 mm
Maximum line Ø (in) 3/8 in
Maximum working load (kg) 1100 kg
Maximum working load (lb) 2425 lb
