Lofrans Tigres Horizontal Windlass
Lofrans Tigres Horizontal Windlass - 1500W / 12V / 8mm is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Lofrans Tigres Horizontal Windlass
The Lofrans Tigres Horizontal Windlass offers the best performance and functionality for when there is adequate deck space or if the chain locker has limited space or for accessibility. Lofrans are the creator of the first windlass, and the Tigres is designed to supply a high torque in all conditions.
The Lofrans Tigres Horizontal Windlass is made from is made from marine grade anodised aluminium alloy to ensure that it's strong, durable and aesthetically pleasing. To show their faith in their product, Lofrans have given the Tigres Windlass a 3 year limited warranty, which can be registered on their website.
Features
- Independent gypsy and drum operation
- Manual chain release
- Manual override
- IP66 rated motor cover
- Marine anodised aluminium body
- Motor size: 1500W
- 3 Years limited manufacturer warranty
Standard Equipment
- Dual direction solenoid pack
- Handle
- Gypsy for chain
- QR code for Instruction manual
Power Supply | 12V | 24V | 48V |
Maximum Pull | 1500kg | 1590kg | 1000kg |
Working Load | 190kg | 200kg | 120kg |
Amps at Working Load | 160A | 90A | 33A |
Line Speed at Working Load | 14 m/min | 16 m/min | 20 m/min |
Max Line Speed | 33 m/min | 33 m/min | 20 m/min |
Net Weight | 28kg | 28kg | 28kg |
