Harken 75mm Block
£119.99
Unit price
/
Unavailable
Tax included
Shipping calculated at checkout.
Harken 75mm Block - Carbo Block With Becket - 2661 is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Harken 75mm Block
From
£104.99
Unit price
/
Unavailable
Harken 75mm Block
Low-friction Carbo Air blocks are lightweight, strong, reliable—and affordable. Companions to our popular Harken Big Boat blocks, these small, compact blocks have very high working loads for safe, easy trimming.
Specifications
| 2660 | 2661 | 2662 | 2670 | 2672 | 2680 | 2682 | 6056 | |
| Sheave Ø (mm) | 75 mm | 75mm | 75mm | 75mm | 75mm | 75mm | 75mm | 75mm |
| Sheave Ø (in) | 2 15/16 in | 2 15/16 in | 2 15/16 in | 2 15/16 in | 2 15/16 in | 2 15/16 in | 2 15/16 in | 2 15/16 in |
| Length (mm) | 137 mm | 165 mm | 152 mm | 137 mm | 103 mm | 137 mm | 103 mm | 117 mm |
| Length (in) | 5 3/8 in | 6 1/2 in | 6 in | 5 3/8 in | 4 1/16 in | 5 3/8 in | 4 1/16 in | 4 5/8 in |
| Weight (g) | 195 g | 214 g | 402 g | 227 g | 179 g | 238 g | 184 g | 221 g |
| Weight (oz) | 6.9 oz | 7.5 oz | 14.2 oz | 8 oz | 6.3 oz | 8.4 oz | 6.5 oz | 7.8 oz |
| Maximum line Ø (mm) | 14 mm | 14 mm | 14 mm | 12 mm | 12 mm | 12 mm | 12 mm | 19 mm |
| Maximum line Ø (in) | 9/16 in | 9/16 in | 9/16 in | 7/16 in | 7/16 in | 7/16 in | 7/16 in | 3/4 in |
| Maximum working load (kg) | 550 kg | 550 kg | 1100 kg | 341 kg | 341 kg | 341 kg | 341 kg | 1361 kg |
| Maximum working load (lb) | 1213 lb | 1213 lb | 2426 lb | 750 lb | 750 lb | 750 lb | 750 lb | 3000 lb |
| Breaking load (lb) | 3638 lb | 3638 lb | 6000 lb | 3000 lb | 3000 lb | 3000 lb | 3000 lb | 6000 lb |
| Breaking load (kg) | 1650 kg | 1650 kg | 2722 kg | 1361 kg | 1361 kg | 1361 kg | 1361 kg | 2721 kg |
| Shackle pin Ø (mm) | 6 mm | 6 mm | 8 mm | 6 mm | - | 6 mm | - | - |
| Shackle pin Ø (in) | 1/4 in | 1/4 in | 5/16 in | 1/4 in | - | 1/4 in | - | - |
| Holding power | - | - | - | 15:01 | 15:01 | 15:01 | - | |
| Fasteners (mm) | - | - | - | - | M5 mm | - | M5 mm | - |
| Clevis pin Ø (mm) | - | - | - | - | - | - | - | 8 mm |
| Clevis pin Ø (in) | - | - | - | - | - | - | - | 5/16 in |
