NEREUS WG200-LL LPG Gas Alarm – Dual Sensor 12/24V Gas Detection System for Boats
The NEREUS WG200-LL is a dual-sensor LPG gas alarm system designed specifically for boats, marine vessels, campervans, caravans, and other enclosed environments where reliable gas leak detection is essential.
Supplied with 2 LPG sensors, the WG200-LL continuously monitors for dangerous propane and butane gas leaks, providing early warning protection before gas concentrations become hazardous. With alarm activation at approximately 10% LEL (Lower Explosive Limit), the system offers dependable safety for engine compartments, cabins, galley areas, and gas storage lockers.
Compatible with both 12V and 24V DC systems, the alarm features compact surface or flush mount installation options, low power consumption, an integrated relay output, and auxiliary buzzer connectivity for enhanced warning capability.
Key Features
- Dual LPG gas detection system with 2 sensors included
- Detects propane and butane gas leaks
- Suitable for 12V and 24V DC installations
- High sensitivity alarm activation at approximately 10% LEL
- Compact surface or flush mount design
- Integrated alarm relay output for external devices
- Auxiliary buzzer output included
- Low current consumption
- Ideal for:
- Boats and yachts
- Motorhomes and campervans
- Caravans
- Commercial vehicles
- Marine engine and galley areas
Technical Specifications
-
Model: WG200-LL
-
Sensor Type: 2 × LPG (Butane/Propane) Sensors
-
Operating Voltage: 10–32V DC
-
Current Consumption: 120mA standby / 180mA alarm
-
Alarm Sensitivity: ~10% LEL (Lower Explosive Limit)
-
Temperature Range: -20°C to +40°C
-
Alarm Relay Output: SPCO, 1A contact rating
-
Auxiliary Buzzer Output: 300mA at supply voltage
Dimensions
Control Panel
- Surface Mount: 96 × 60 × 26mm
- Flush Mount: 96 × 60 × 5mm
Sensor
- Surface Mount: 35 × 35 × 26mm
- Flush Mount: 35 × 35 × 5mm
A reliable dual-zone LPG safety solution for marine and mobile installations requiring continuous propane and butane gas monitoring.
